7. System configuration
▶ System
▶ Product specification
Fig. 54) System window
Fig. 55) Product specification screen
Select the language (Korean / English / Chinese).
Select the logo displayed for the booting.
Configure the user password to check the password
to change the touch lock function or to enter the
system configuration window. (However, the system
does not check the password to enter the system
configuration window if the user password is "0".)
Upload the user logo using the SD card.
(Not work during recording)
Enter the information displayed for the
booting.
Check whether to display the product
information for the booting.
Display the product version information.
Parameter Initial value Configuration range
Language English Korean, English, Chinese (simplified/traditional)
Logo GR200 logo GR200 logo, user logo
Password 0000 0 ~ 9999
Parameter Initial value Configuration range
Info 1 HANYOUNG NUX CO.,LTD. Enter the text (up to 30 characters)
Info 2 GR200 GRAPHIC RECODER Enter the text (up to 30 characters)
Info 3 www.hynux.com Enter the text (up to 30 characters)
Information Use Unused, use
[ System parameter ]
[ Product specification parameter ]
The logo image file has the resolution of
640x480 and the file name of GR200_LOGO.
bmp. In addition, the file shall be located in
the "GR200_LOGO" folder in the root directory
of the SD card. Otherwise, the upload fails.
Caution
Initialize the parameters. Events or error
history is not initialized.
(Not work during recording)
Caution
