▶ Alarm output
Maximum number of outputs 12
Output type Relay output
Maximum ratings 5 A 250 V AC, 5 A 30 V DC
Recommended ratings 3 A 250 V AC, 3 A 30 V DC
Relay life
50,000 times at the maximum ratings, 100,000 times at the
recommended ratings
Display
TFT color LCD
(115.2 × 86.4 ㎜, resolution : 640 × 480 pixel, LED Backlight)
Backlight life 40,000 hours
Language in use Korean, English, Chinese (simplified/traditional)
Save function
Internal memory - volatile memory : 900 KB - Save up to 4 hours with
the interval of 1 second
- Non-volatile memory : 80 MB – Save up to 15 days
with the interval of 1 second
External memory - SD card (2GB) : Save up to a year with the interval of
1 second ※ Support the SDHC
Save period User configuration (1, 2, 5, 10, 20, 30, 60, 120 seconds)
Memory information
Measurement from each channel, Burn-out, DI (contact input),
ALARM, relay output status
● The sensor input terminal is insulated among the input channels. It is insulated with the relay output terminal,
the contact input terminal and the communication terminal.
● The relay output terminal is not insulated among the output terminals. It is insulated with the contact input
terminal and the communication terminal.
● The contact input terminal is not insulated among the input terminals. In addition, it is not insulated with the
communication terminal.
● The power terminal is insulated with other input and output terminals and the internal circuit.
● The FG terminal is insulated with other input and output terminals and the internal circuit.
Reference
5. Installation environment
4. Memory specification
3. Display specification
▶ Use environment
Ambient temperature 0 ~ 50 °C
Temperature change 10 °C/h or below
Ambient humidity 20 ~ 90 % RH (no condensation)
Magnetic field 400 A/m or less
Altitude Less than 2,000 m above the sea level
Weight About 1.32 ㎏
