HANYOUNG NUX GR200 Series User Manual

Graphic Recorder
2
Main body 4 body clamps 250 Ω resistor SD card Manual
Before start
1. Check the product
Thank you for purchasing the graphic recorder of HANYOUNG NUX (Model : GR200).
The manual specifically explains the functions, how to install, caution and instruction of the
product. Please carefully read and fully understand the manual.
In addition, let the manual used by and delivered to the end-user and keep the manual in
a place ready to read.
(The contents of the manual may be altered without prior notice depending on the
improvement or functional changes of the product.)
After purchasing the product, please check whether the product meets your desired specification and
then check the damages on the exterior or missing parts.
▶ Parts
▶ Suffix code
Model Code Description
GR200 -
◻ ◻ ◻
Graphic recorder
Number of
channels
2 2 channel
4 4 channel
8 8 channel
12 12 channel
External contact
input & output
(DI / DO)
N None
1 DI 2 contacts + DO 6 contacts (relay)
2 DI 4 contacts + DO 12 contacts (relay)
Communication 0 RS 422/485
※Ethernet is available when using our ethernet converter(HMCE).
