Parameter Initial value Configuration range
LIST 1 START
Enter the text
(up to 16 characters)
LIST 2 STOP
LIST 3 CHECK POINT
LIST 4 OK
LIST 5 NG
LIST 6 -
LIST 7 -
LIST 8 -
Parameter Initial value Configuration range
Line thickness 2 pixel 1 pixel, 2 pixels
Draw method Dot Dot, line
Record file name GR200_ Enter the text (up to 6 characters)
Initial operating screen Trend screen
Trend screen, See text message,
Bar graph
[ LIST parameter ]
[ Graph parameter ]
▶ LIST
▶Graph
Fig. 32) LIST screen
Fig. 33) Graph screen
Enter the message frequently used on the
trend screen.
The file name goes back to "GR200_" when the leading character is missing or blank.
“ / ” may not be used as the file name.
Caution
Configure the line thickness of the graph on
the display.
Configure the display method of the graph.
Configure the saved file name.
The screen is shown up firstly by selecting an
operating screen which you frequently use.
