13
The pull chain located on the switch housing
has four positions to control fan speed. One
pull is HIGH, two is MEDIUM, three is LOW
and four turns the fan OFF. (Fig. 1)
The pull chain in the middle is used to turn the
light ON or OFF. (Fig. 2)
The pull chain extension (F) supplied in one of
the hardware packs or a custom pull chain
extension (sold separately) may be attached to
fan pull chain. (Fig. 3)
Locate cap (K) in one of the hardware packs and
place cap (K) firmly in hole in middle of switch
housing cap. Align holes in switch housing cap with
holes in switch housing and secure switch housing
cap with three screws that were removed in Step 4 of
“Final Installation” section (page 10). Tighten all three
screws securely. (Fig. 2)
OPERATION INSTRUCTIONS
2.
3.
1.
2.
F
2
3
C
Switch
Housing
Switch
Housing
Cap
Switch
Housing
Cap Screw
K
1
2
Switch
Housing
INSTALLING FAN WITHOUT INCLUDED LIGHT KIT (OPTIONAL)
