4 - System setup
21
Speed transducer for tractor
It is possible to connect a speed sensor from tractor gearbox or radar/
GPS to the controller. A speed/switch harness (A) and extension cable
are needed to connect the speed transducer to the Controller/Terminal.
Foot pedal remote ON/OFF (optional)
Note the following if the Foot pedal remote is to be fitted.
Remote ON/OFF switch has to be activated from the extended menu at
installation. The HARDI Service centre does this.
The speed/switch harness (A) is connected to the Controller/Terminal.
Connect the plug from the Foot pedal ON/OFF to the correct connector
on harness (A).WARNING! Connector “H” must be connected to ± pole
on the battery. Do NOT connect to ground on tractor as this might blow
the controller!
μ
ATTENTION! The main ON/OFF valve switch at Spray Box
overrides all remote switches. It must be set to ON for the
optional Remote ON/OFF switch to function.
