CUS-013-0044-01 Page 15 of 26
4.4.2. Unloading the Skewers
USE PROTECTIVE CLOTHING WHEN LOADING AND UNLOADING THE ROTISSERIE.
1. Open the door to stop the drive rotation. Use the green manual advance switch to position the drive
assembly as required.
2. Referring to figure below, remove each skewer by lifting the left end, sliding the skewer through
the plate hole, and then, as show in figure below, gently pivot the skewer out of the rotisserie.
3. Place each skewer on a skewer cart or a cooked food table.
4. Use the green manual advance switch to position skewers as required for removal.
5. Close the door of the rotisserie to resume operation or cooking.
6. If no further cooking is required, push in the main ON/OFF red switch to end the cook cycle.
Refer to section 3.5 Control Panel Layout on page 10 to identify the controls.
LIFT AND SLIDE THE SKEWER
THROUGH THE HOLE
GENTLY PIVOT THE RIGHT SIDE
OUT OF THE DRIVE PLATE
