Hardt Blaze - Double-Stacked Swing Door Rotisserie

Page 8 of 26 CUS-013-0044-01
Double-Stacked Swing Door Rotisserie
Figure 3-3
For a full list of available accessories, please visit www.hardtequipment.com or contact your sales account representative.
CONTROL PANEL
RED MAIN ON/OFF SWITCH
GREEN MANUAL
ADVANCE SWITCH
WATER INLET
VALVE HANDLE
MANUAL DRAIN
VALVE HANDLE
(UPPER ROTISSERIE)
GAS INLET
WATER INLET
DRAIN
(UPPER ROTISSERIE)
TOP VENT
(UPPER ROTISSERIE)
HALOGEN LIGHT
ACCESS PANEL
CIRCUIT BREAKER
POWER CORD
CONTROL PANEL
DRAIN
(LOWER ROTISSERIE)
HALOGEN LIGHT
ACCESS PANEL
CHIMNEY
(LOWER ROTISSERIE)
MANUAL DRAIN VALVE
HANDLE
(LOWER ROTISSERIE)
RED MAIN ON/OFF SWITCH
GAS
PRESSURE
GAUGE
SERIAL
NAMEPLATE
FLAME SENSOR
ACCESS PANEL
RESTRAINING
CABLE
SERIAL NAMEPLATE
