Hardt Blaze - Replacing the Halogen Lamp

Page 24 of 26 CUS-013-0044-01
6.3. Replacing the Halogen Lamp
1. Turn the rotisserie OFF (push the main ON/OFF
switch in) and disconnect the power cord from the
wall receptacle.
2. Allow the rotisserie to sufficiently cool down.
3. Remove the halogen light access panel located on
the left side of the rotisserie by loosening the thumb
screws by hand (Figure 6-3).
Figure 6-3
4. Loosen the wing nuts on the halogen light bulb
support bracket in order to access the halogen light
bulb (Figure 6-4).
Figure 6-4
5. While wearing gloves, gently pull the old halogen light
bulb out of its fixture (Figure 6-5).
Figure 6-5
THUMB SCREW
