Double-Stacked French Door Rotisserie
Figure 3-4
For a full list of available accessories, please visit www.hardtequipment.com or contact your sales account representative.
CONTROL PANEL
RED MAIN ON/OFF SWITCH
GREEN MANUAL ADVANCE SWITCH
WATER INLET
VALVE HANDLE
MANUAL DRAIN
VALVE HANDLE
(UPPER ROTISSERIE)
GAS INLET
WATER INLET
DRAIN
(UPPER ROTISSERIE)
TOP VENT
(UPPER ROTISSERIE)
HALOGEN LIGHT
ACCESS PANEL
CIRCUIT BREAKER
POWER CORD
CONTROL PANEL
DRAIN
(LOWER ROTISSERIE)
HALOGEN LIGHT
ACCESS PANEL
CHIMNEY
(LOWER ROTISSERIE)
MANUAL DRAIN
VALVE HANDLE
(LOWER ROTISSERIE)
RED MAIN ON/OFF SWITCH
GREEN MANUAL ADVANCE SWITCH
WATER INLET VALVE
HANDLE
FLAME SENSOR
ACCESS PANEL
RESTRAINING
CABLE
SERIAL NAMEPLATE
SERIAL
NAMEPLATE
GAS
PRESSURE
GAUGE
