3. Equipment Diagrams
Single Swing Door Rotisserie
Figure 3-1
For a full list of available accessories, please visit www.hardtequipment.com or contact your sales account representative.
CONTROL PANEL
RED MAIN ON/OFF SWITCH
GREEN MANUAL ADVANCE SWITCH
WATER INLET
VALVE HANDLE
MANUAL DRAIN
VALVE HANDLE
(COOK/CLEAN)
GAS INLET
WATER INLET
DRAIN
TOP VENT
HALOGEN LIGHT
ACCESS PANEL
CIRCUIT BREAKER
POWER CORD
FLAME SENSOR
ACCESS PANEL
RESTRAINING
CABLE
SERIAL
NAMEPLATE
GAS
PRESSURE
GAUGE
