July 2006 Rev 8 1/34
1
M24C64-W M24C64-R M24C64-F
M24C32-W M24C32-R M24C32-F
64 Kbit and 32 Kbit Serial I²C bus EEPROM
Feature summary
■ Two-Wire I
2
C serial interface
Supports 400kHz Protocol
■ Single supply voltage:
– 2.5 to 5.5V for M24Cxx-W
– 1.8 to 5.5V for M24Cxx-R
– 1.7 to 5.5V for M25Cxx-F
■ Write Control Input
■ Byte and Page Write (up to 32 Bytes)
■ Random And Sequential Read modes
■ Self-Timed programming cycle
■ Automatic address incrementing
■ Enhanced ESD/Latch-Up Protection
■ More than 1 Million Write cycles
■ More than 40-year data retention
PDIP8 (BN)
SO8 (MN)
150 mil width
TSSOP8 (DW)
169 mil width
UFDFPN8 (MB)
2x3mm² (MLP)
www.st.com
