Harman P35I Owner's Manual

11
Pellets or Corn/Pellet Mixture Only
P35i Fireplace Insert
Save These Instructions 3-90-775R15_04/13
F. Factory-Built Fireplace
Installation
WheninstallingtheP35iInsertintoafactorybuiltwood
burningreplace,severalthingsneedtobetakeninto
consideration.
Thesizeofthereplaceopening.Willtheunittinto
theopening?Someofthefactorybuiltreplaceshave
metalsmokeshieldsinsidethetopthatcanberemoved
to gain height. Keep in mind that anything removed
fromthefactorybuiltreplacemustbeattachedtothe
replacewithametalwire.Floorprotectionguidelines,
aslistedpreviously,mustalsobefollowed.
Themanufacturedreplacemaynotbealteredbeyond
the exceptions listed below. Never remove masonry
bricksormortarfromanexistingreplace.
Thefollowingmodicationsarepermissible:
• Removalofthedamperorlockinopenposition
• Removalofsmokeshelforbafe
• Removalofandironsorembercatchers
• Removalofloggrate
• Removalofviewscreenorcurtain
• Removalofdoors
• Externaltrimpieces,thatdonotaffecttheoperation
ofthereplace,mayberemovedprovidingtheycan
bestoredonorwithinthereplaceforreassembly
iftheinsertisremoved.
• Ifthehearthextensionislowerthanthereplace
opening,theportionoftheinsertextendingontothe
hearthmustbesupported.
• Finalapprovalofthistypeofinstallationiscontingent
upontheauthorityhavingjurisdiction.
Note:IftheHarman®P35iInsertisinstalledintoafactorybuiltwoodburningreplace,this
label(Harman®part#3-90-00675)MUSTbeattachedtothealteredreplace.
ThefactorybuiltchimneymustbelistedperUL127(US)
andmeettypeHTrequirementsofUL103(US).Factory
BuiltreplacechimneystestedtoUL127-98maybe,atthe
replacemanufacturersoption,testedtothesamecriteria
asUL103HTrequirements.Ifthechimneyisnotlistedas
meetingHTrequirements,orifthefactorybuiltreplacewas
testedpriorto1998,afullheightlistedchimneylinermustbe
installedfromtheapplianceuecollartothechimneytop.
Linermustmeethightemperature(2100F)perUL1777(US).
Thelinermustbesecurelyattachedtoboththeuecollar
andthechimneycap.Topreventroomairpassagetothe
chimneycavityofthereplace,sealthedamperareaaround
thechimneylinerwithberglassbatting.
Hearth must be constructed to
the proper height and finished
with a non-combustible
material.
IN CANADA: This replace insert
must be installed with a continuous
chimney liner of a minimum 3"
diameter extending from the insert to
the top of the chimney. The chimney
liner must conform to the Class 3
requirements of CAN/ULC-S635,
Standard for Lining Systems for
Existing Masonry or Factory Built
Chimneys and Vents, or CAN/ULC-
S640, Standard for Lining Systems
for New Masonry Chimneys.
When using single-wall
venting or ex,this section
of venting must be wrapped
with a non-combustible
insulation to prevent excess
temperatures within the
replace and on the fuel
hopper.

Harman P35I Specifications

General

Fuel Type	Pellet
Power Source	Electric
Adjustable Thermostat	Yes
Remote Control	Yes
Overheat Protection	Yes
Color	Black
BTU Input	35, 000 BTU
Safety Features	Automatic shutdown
