20
P35i Fireplace Insert
Pellets or Corn/Pellet Mixture Only
Save These Instructions
3-90-775R15_04/13
Mostimportantly, theframe mustbelevel.Again, be
certainthatthesurroundisnotsupportingtheweight.
Turnthelevelingscrewsinuntilthere isaslightgap
beneaththesurroundpanels.
Hereareafewdifferentwaystoanchorthemounting
frame.
Onthesidesoftheframe,
thereareafewholeswhich
can be used to attach
metalstraps.Thesestraps
can be anchored into the
replace using masonry
anchors. You could also
use any of the unused
holesinthebottomofthe
frame to install anchors
and lag bolts. Another
optioninvolvesusingkit#
1-00-774279.Here,youwillmountplatestotheframe.
Theseplateshavecouplingnutsweldedtothem.The
kit alsoincludestwo pieces of 1/2" allthread,which
threadsintothecouplingnuts.Thesecanbeusedto
tightenupwardagainstthelinteluntiltheunitissecure.
E. Attaching the Venting
The ue collar on the rear of the mounting frame is
designedtopivot.Loosenthefourmountingboltsand
adjusttheangleofthecollarasneeded.Shownabove
istheverticalpositionandthehorizontalposition.Be
sure the ber gasket remains in place between the
collarandthemountingframe,andsecurethebolts.
Secure the rst section of venting to the collar with
a minimum of two fasteners. Self-drilling screws will
workwellforthis.Oncetheventingissecuredandthe
seamsaresealed,itisrecommended thatyouwrap
the vent pipe with a non-combustible insulation to
preventoverheatingofthemotorsandotherappliance
components. This is required (and supplied) when
usingtheoptionalZeroClearanceCabinet.
The mounting frame is the anchor for the appliance.
If the frame is not secured properly, shifting will
occur when sliding the insert in or out.
D. Securing the Mounting Frame
The mounting frame is the anchor for the appliance.
If the frame is not secured properly, shifting will
occur when sliding the insert in or out.
The stove is supplied with a Leg Leveler Kit that
contains (4) 5/16-18 X 1". These bolts should be
threaded down through the holes to raise the frame
cornersasneeded,tolevel.
NOTE: When installed in a rear vent conguration, the maximum BTU
maybereduced due toelevatedESPtemperaturesassociated with the
horizontalexhauststream.
Strapscould
attachhere
LevelerBolts
