Harman P35I - Custom Surround Sizes

3-90-775R15_04/13
Service Parts
P35i Pellet Insert
Beginning Manufacturing Date: July 2010
Ending Manufacturing Date: Active
IMPORTANT:THISISDATEDINFORMATION.Whenrequestingserviceorreplacement
partsforyourappliancepleaseprovidemodelnumberandserialnumber.Allpartslisted
inthismanualmaybeorderedfromanauthorizeddealer.
Stocked
at Depot
ITEM Description COMMENTS PART NUMBER
27 ULFeederAssembly 1-10-774000A
Y
27.1
PelletFeederCWMotor-4RPM 3-20-60906 Y
27.2
FeederMotorBracketw/Grommet 1-00-247406 Y
27.3
Bearing3/8IDX1-1/8OD 3-31-3014 Y
CastCamBlock 3-00-677154 Y
27.4
PelletFeederBearingRETNRw/Bolts 1-00-04035 Y
27.5
PelletFeederAuger 3-50-00565 Y
27.6
FeederAirCrossoverKit 1-00-67900 Y
9MMX13MMTubingKit 5Ft 1-00-511427 Y
27.7
1/8SiliconeTubing 5Ft 1-00-5113574 Y
27.8
Screws-HWHTEKS10X3/4 Pkgof100 3-30-5004-100 Y
27.9
PelletAirIntakew/Gasket 1-10-06810A
27.10
Gasket,FeederAirIntake Pkgof6 3-44-72224-6 Y
27.11
SnoutWeldmentw/Gasket 1-10-774143A
27.12
PelletFeederWeldment 1-10-724132 Y
27.13
Flange1/4-20X3/8 Pkgof50 3-30-2000-50 Y
27.14
PillowBlock-1/2in Pkgof4 3-31-3614087-4 Y
27.15
WingNut,5/16-18 Pkgof25 3-30-8012-25 Y
27.16
ShortFeedCVR&Gasket 1-00-677122 Y
27.17
PusherArmAssembly 1-10-774354W Y
27.18
SlidePlate 1-10-677121A Y
27.19
Nut,FHN5/16-18Z5 Pkgof100 3-30-8005-100 Y
27.20
Grommet-1/2inID-Thick Pkgof12 3-31-2761-12
GasketHopperThroat 3-44-677185
Y
Gasket,Snout Pkgof10 3-44-677160-10
Y
HopperSwitchFeederFitting Pkgof2 1-00-142818
Y
27.1
27.2
27.3
27.4
27.5
27.6
27.7
27.8
27.9
27.10
27.11
27.12
27.13
27.14
27.15
27.16
27.17
27.18
27.19
27.20
#27 Feeder Assembly
