Harris HFS6801+ - Back Connectors

6 HFS6801+ Installation and Operation Manual
Chapter 1: Introduction
Back Connectors
Figure 1-2 shows the double-slot back connector used by the
HFS6801+ module when installed in an FR6802+XF frame.
Figure 1-2. HFS6801+ Back Connector
SDI IN
AUX IN
GENLOCK
2
4
5
6
1
3
SDI
OUT
SDI
OUT/
RCLK
DATA I/O
SDI video in
Auxiliary input
SDI video
outputs
SDI5 and SDI6
outputs are
reclocked
SDI video
outputs
Analog
reference input
Audio/video
timing output
