28HFS6801+ Installation and Operation Manual
Chapter 3: Operation
Setting HFS6801+ Control Parameters
Table 3-3 lists all of the available parameters and options for the
HFS6801+. All parameters clip unless otherwise indicated.
The sequence of options listed in the Options column mirrors the
sequence achieved when you move the Navigation Toggle switch
up.
The On/Off combinations of the control LEDs on the card-edge indicate
the active bank number. See “Changing Parameter Settings” on page 26
for more information.
Legend
Bold option = Indicates that this is the default setting for the parameter
[RO] = Indicates that parameters are read-only/feedback, and cannot be
used to select controls
1(superscript digit)
= Indicates that there is a footnote for this parameter
entry, found at the end of the tables
