10 HFS6801+ Installation and Operation Manual
Chapter 2: Installation
Maximum 6800+ Frame Power Ratings
The power consumption for a HFS6801+ module is 7 W from the
positive supply and 0.3 W from the negative supply.
Table 2-1 describes the maximum allowable power ratings for 6800+
frames. Note the given maximums before installing any 6800+ modules
in your frame.
Table 2-1. Maximum Power Ratings for 6800+ Frames
6800+ Frame
Type
Max. Frame
Power
Dissipation
Number
of Usable
Slots
Max. Power
Dissipation
Per Slot
FR6802+XF
(frame with AC power
supply)
120 W 20 6 W
FR6802+XF48
(frame with DC power
supply)
105 W 20 5.25 W
FR6802+QXF frame
(with AC or DC power
supply)
120W 20 6 W
