14 HFS6801+ Installation and Operation Manual
Chapter 2: Installation
Installing 6800+ Modules
Required Frames and Back Connector Types
The HFS6801+ modules have double-width back connectors that can
be installed in an FR6802+XF or FR6802+QXF frame. HFS6801+
modules cannot be installed in a FR6802+DM frame, a FR6800/7000
frame, or a frame without fans.
See the FR6802+ Frame Installation and Operation Manual for details
on installing back connectors in an FR6802+ frame.
A FR6802+RM (Rear Support Extension Rails for 6800+ series
frames) option is recommended for the HFS6801+ modules. See your
FR6802+ Frame Installation and Operation Manual for installation
instructions.
Installing and Removing Modules
These modules require no specialized installation or removal
procedures. However, if installing both front and rear modules, ensure
that the back module is installed first before plugging in the front
module.
Before removing, inserting, or replacing a back module in your
frame, you must remove power from the frame. Failure to power
down the frame could result in damage to the frame, modules, or
power supply.
When removing both the front and rear modules, ensure that the front
module is unplugged from the frame first, before removing the rear
module.
• See the FR6802+ Frame Installation and Operation Manual for
information about installing and operating an FR6802+ frame and
its components.
• See the 6800+ Safety Instructions and Standards Manual for
important information about safely installing your module.
