Harris HFS6801+ - Outputs; SDI Video Output

HFS6801+ Installation and Operation Manual 41
Chapter 4: Specifications
Outputs
SDI Video Output
Item Specification
Number 2 reclocked, 4 synchronized
Standard
• 1080i (SMPTE 274M) at 25/29.97/30 Hz
• 1080p (SMPTE 274M) at 23.98/24/25/29.97/30
Hz
• 720p (SMPTE 296M) at 50/59.94/60 Hz
• 525/625 (SMPTE 259M)
Connector BNC (IEC169-8)
Impedance 75Ω
Return loss
• >18 dB (typical) from 5 MHz to 1485 MHz
HD-SDI mode
• >18 dB (typical) to 270 MHz SD-SDI mode
Signal level 800 mV ±10%
D.C. offset 0.0 V pk-to-pk ±0.5 V
Rise/fall time
• < 270 ps, within 100 ps of each other HD-SDI
mode
• 400-1500 ps (20 to 80% amplitude) SD-SDI mode
Overshoot <10% of amplitude
Jitter
• >100 kHz: <135ps
10 Hz to 100 kHz: <675 ps
in HD-SDI mode
• < 0.2 UI (740 ps) peak-to-peak in SD-SDI mode
Delay
• 1080i/1080p: up to 8 frames less 2 lines
• 720p: up to 16 frames less 2 lines
• 525/625: up to 1 frame
Frame Synchronizer
Locking Range
At least ±50 ppm
