HFS6801+ Installation and Operation Manual 9
Chapter 2
Installation
Overview
This chapter describes the HFS6801+ installation process, including the
following topics:
• “Maximum 6800+ Frame Power Ratings” on page 10
• “Unpacking the Module” on page 11
• “Setting Jumpers” on page 12
• “Installing 6800+ Modules” on page 14
• “Making Connections” on page 15
• “Upgrading Module Firmware” on page 16
See the FR6802+ Frame Installation and Operation Manual for
information about installing and operating an FR6802+XF frame and
its components.
Before installing this product, read the 6800+ Series Safety
Instructions and Standards Manual shipped with every FR6802+
Frame Installation and Operation Manual or downloadable from our
Web site at www.broadcast.harris.com/leitch
. This safety manual
contains important information about the safe installation and
operation of 6800+ series products.
