38HFS6801+ Installation and Operation Manual
Chapter 3: Operation
Alarms
The table below describes the specific alarms for the HFS6801+
module. You can only identify specific alarms using a software control
application (for example, +Pilot Lite or Pilot). For more information,
see the following:
• Table 3-7 (below) for a list of HFS6801+ alarms that are logged
and monitored via CCS applications
• The appropriate software control user manual or online help for
more information
Note
The RefPresAlarm, RefLockedAlarm and RefStdMismatch
alarms are disabled when the Frame Sync Mode parameter is set
to Delay Mode.
Table 3-7. Alarm Descriptions
Alarm Name Alarm Description Alarm Level
SDI IP Video Present Loss of SDI Major
Video Frozen Video freeze Minor
RefPresAlarm Loss of reference Major
RefLockedAlarm Loss of
reference_locked
Major
RefStdMismatch Mismatch between
reference video and
video standard
Major
StdMisMtch Video format selection
error
Major
