HFS6801+ Installation and Operation Manual29
Chapter 3: Operation
Table 3-3. Parameter Options
Bank,
Rotary
Switch
Parameter Name Function Options
Bank 0
0, 1 SDI IP Video Std Set Selects the SDI input video signal standard
•SD 525
•SD 625
• 1080I 30
• 1080I 29.97
• 1080I 25
• 1080P 30
• 1080P 29.97
• 1080P 25
• 1080P 24
• 1080P 23.98
• 720P 60
• 720P 59.94
• 720P 50
0, 2 Y CRC Err Cnt Clear Clears the luminance CRC error counter
•On
•Off
0, 3 C CRC Err Cnt Clear Clears the chrominance CRC error counter
•On
•Off
0, 4 EDH Error Cnt Clear Clears EDH error counter
•On
•Off
0, 5 Frame Sync Mode Selects the operational mode for the frame
synchronizer
• Sync Mode
• Delay Mode
0, 6 Force Freeze Forces the output video to freeze
•Off
•On
0, 7 Freeze Type Selects the type of manual video freeze
• Field 1
•Field 2
•Frame
0, 8 Video OP Mode Selects the output video mode when the
input video is disrupted
• Pass
• Black
• Freeze
