30HFS6801+ Installation and Operation Manual
Chapter 3: Operation
0, 9 Vertical Phase * Adjusts the vertical timing
• 0 to 1124 Ln
• 0 to 524 Ln
• 0 to 624 Ln
• 0 to 749 Ln
(see “Cross-Functional
Parameter Changes” on
page 34)
0, A Horizontal Phase * Adjusts the horizontal timing
• 0.0 to 35.542 µs
• 0.0 to 22.209 µs
• 0.0 to 22.231 µs
• 0.0 to 26.653 µs
• 0.0 to 29.616 µs
• 0.0 to 29.646 µs
• 0.0 to 37.024 µs
• 0.0 to 37.061 µs
• 0.0 to 63.519 µs
• 0.0 to 63.963 µs
(see cross-functional
parameter changes
table)
0, B Delay Range * Adjusts the amount of frame delay
• 0 to 7 frm
• 0 to 1 frm
• 0 to 15 frm
(see “Cross-Functional
Parameter Changes” on
page 34)
0, C Y Offset Adjusts offset for the Y channel -100.685 to 100.685 mV
(0.0)
0, D Cb Offset Adjusts offset for the Cb channel -100.685 to 100.685 mV
(0.0)
0, E Cr Offset Adjusts offset for the Cr channel -100.685 to 100.685 mV
(0.0)
0, F Factory Recall Recalls the factory settings
•Off
•On
Bank 1
Table 3-3. Parameter Options (Continued)
Bank,
Rotary
Switch
Parameter Name Function Options
