HFS6801+ Installation and Operation Manual 21
Chapter 2: Installation
Manually Adding a Device to the Discovery or Network Folder
If your device is not listed in the Discovery or Network folder, you
must manually add it to these folders. After you add the device, you can
use the Software Upgrade dialog box to continue with the module
firmware upgrade.
To manually add a device to the Discovery or Network folder, follow
these steps:
1. Enter Build mode, and then drag or copy and paste the module’s
device icon from the Catalog folder into the Network or Discovery
folder.
2. Right-click the device icon, and then select Properties.
3. On the Device tab of the Navigation Properties box, enter the IP
address of the frame that holds the module. (See Figure 2-6.)
Figure 2-6. Navigation Properties Box
If you make changes in the last field (located above and to the right
of the Set Default button), you may lose your connection to the
module. If this happens, you will need to rediscover the module.
Do not make changes in
this field
Enter frame IP address here
Frame number=0
Slot number=17
Must be set to 1
