HFS6801+ Installation and Operation Manual33
Chapter 3: Operation
[RO] EDH Present Reports the presence of EDH in the input
SDI signal
•No
•Yes
[RO] EDH Error Count Reports the number of occurred EDH errors 0 to 32767
[RO] Vieo Frozen Reports the output video frozen status
•No
•Yes
[RO] GL Video Present Reports the presence of the video signal
from the external reference source
•No
•Yes
[RO] GL Video Locked Reports the locked status of the external
reference signal
•No
•Yes
[RO] Genlock Std
Feedback
Reports the detected Genlock standard
• Unknown
• 1080P 25
• 720P 59.94
• 720P 60
• 1080P 23.98
• 1080P 24
• 1080P 29.97
• 1080P 30
• 1080I 25
• 1080I 29.97
• 1080I 30
• SD525
• SD625
• 720P 50
• 1080Psf 23.98
• 1080Psf 24
Notes:
1. The frame rate for both input video and reference video must match.
Table 3-3. Parameter Options (Continued)
Bank,
Rotary
Switch
Parameter Name Function Options
