36HFS6801+ Installation and Operation Manual
Chapter 3: Operation
1080I Indicates if a 1080I video
source is present
• GREEN: 1080I
video present
• OFF: 1080I video
not present
1035I Indicates if a 1035I video
source is present
• GREEN: 1035I
video present
• OFF: 1035I video
not present
1080P/sF Indicates if a 1080P/sF video
source is present
• GREEN: 1080P/sF
video present
• OFF: 1080P/sF
video not present
525 Indicates if a 525 video source
is present
• GREEN: 525 video
present
• OFF: 525 video not
present
625 Indicates if a 625 video source
is present
• GREEN: 625 video
present
• OFF: 625 video not
present
Reference Present Indicates the presence of the
reference signal either from
the back module or internally
from the NEO frame
• GREEN: Genlock
present
• OFF: Genlock
absent
Freeze Illuminates if the frame
synchronizer circuitry is
currently freezing the output
video
• AMBER: Output
video frozen
• OFF: Output video
not frozen
Table 3-5. Monitoring LEDs (Continued)
LED Description Color Indication
