3
3. Specifications
Model C14
Power 2.2 kW 3HP
Rated Voltage 230 V
Phase 1-Ph
Frequency 50 Hz 60 Hz
Full-Load Current 12.8 A
Wheel Dia. 350 mm 14″
Blade Length 3175 mm 125 ″
Blade Width 3-25 mm 1/8 - 1″
Speed of Saw Blade 1050 m/min
Max. Cutting Height 350 mm 14″
Throat Capacity 330 mm 13″
Fence Plate Height 14/80 mm 1/2” / 3″
Work Table Size 500×400 mm 19-3/4×15-3/4″
Work Table Height 870 mm 34-1/4″
Foot Size 610×400 mm 24″×15-3/4″
Total Height 1800 mm 71″
Net Weight 150 kg 330 lbs
Gross Weight 170 kg 374 lbs
Packing Size 750×495×1920 mm 29-1/2x19-1/2x75-5/8″
Notice to California Residents: This product can expose you to wood dust, which is known to
the State of California to cause cancer. For more information, go to
www.P65Warnings.ca.gov.
