2. Select Drug library mode in main menu
(Fig. 814-11)
Select drug category / type, then select drug name, input parameters and press OK key to save them.
To re-select the infusion mode, press Return key to exit.
3. Setting Range of parameters in each Infusion Modes (For Reference)
Preset volume : 0000.00-9999.99ml
flow rate : 0.10-1800.00ml/h
Volume limit : 0.01-9999.99ml
Infusion Time : 0hrs1min-99hrs59min
Weight Dose : 0.001-9999.999
Dosageunits:mg/kg/h,mg/kg/min ,ug/kg/h,ug/kg/min,Mmol/kg/h,M
