2.1 Configuration
Basic device,
type
Interfaces Inputs / outputs Amplifier to
install
AED9101D RS232, RS485 Trigger input
AD103C
AED9201B RS232, RS485 Digital I/O
(electrically
isolated)
AED9301B PROFIBUS Digital I/O
(electrically
isolated)
AED9401A CANopen or
DeviceNet
Digital I/O
(electrically
isolated)
AED9501A CANopen or
DeviceNet
Trigger input
Digital inputs and outputs allow:
• processes to be controlled via four limit values
• triggered measured values to be determined (MAV) and
• a filling or dosing process to be controlled.
• A diagnostic function has been built into the AD103C to analyze dynamic
measurement. This function includes a memory for 512 (binary) measured
values and associated status information. Different recording modes are
available so that the processes can be analyzed without interrupting mea-
surement.
