Safety instructions
DMP41 A03470_07_E00_00 HBM: public 11
Ferrite Ferrite
Fig. 2.1 Position of the ferrites
Important
The distance between ferrite and plug must not exceed 2 cm
The DMP41 thus essentially satisfies the highest requirements and is there
fore suitable for use in all environments described in the product standard.
Conversions and modifications
The DMP41 must not be modified in terms of design or safety engineering
except with our express agreement. Any modification shall exclude all
liability on our part for any resultant damage.
In particular, any repair or soldering work on motherboards is prohibited.
When exchanging complete modules, use only original parts from HBM. The
DMP41 is delivered from the factory with a fixed hardware and software
configuration. Changes can only be made within the possibilities docu
mented in the manuals.
Ensure that the electrical safety of the DMP41 has been confirmed after a
conversion or repair.
