Electrical connections
Transducer connection
26 A03470_07_E00_00 HBM: public DMP41
4.2 Transducer connection
Important
Connect transducers either to the upper 15-pin socket or to the lower
Amphenol socket. Simultaneous connection of transducers in both sockets
will result in incorrect measurement results.
Full bridge stain gage transducer; MS cable connector, 7-pin, MS3106A 16S-P (HBM ordering number 1-MS3106 PEMV)
Full bridge strain gage transducer; D-sub, 15-pin, DA-15P (HBM ordering number 3-3312.0182)
