Electrical connections
Transducer connection
32 A03470_07_E00_00 HBM: public DMP41
log measurement signal) and a data mode (the lead transfers the digital
TEDS data).
Full bridge strain gage, can be combined with TEDS inputs.
8
5
6
15
13
12
Hsg.
wh
bk
rd
bu
gn
gy
ye
1
2
4
3
Measurement signal (+)
Bridge excitation voltage (+)
Sense lead (-)
Sense lead (+)
Bridge excitation voltage (-)
Measurement signal (-)
Cable shield
1)
Cable color code: wh= white; bk= black; bu= blue; rd= red; ye= yellow; gn= green; gy= gray
9
2
3
Voltage supply + 16 V
Voltage supply - 16 V
4
Hsg.
A
B
C
D
F
G
G
D
EB
F
C
A
MS cable connector, 7-pin,
MS3106A 16S-P
D-sub, 15-pin DA‐15P
Zero-wire: Between 2 and 2' Between B and G
TEDS 1-Wire® data
TEDS
1-Wire® ground
ye
bk
DATA
TEDS module (optional)
1-TEDS-BOARD
8
1
15
9
