Electrical connections
PC connection
36 A03470_07_E00_00 HBM: public DMP41
PC connection via USB serial adapter
USB serial
adapter
USB HOST
ETHERNET
1 DMP41
1 adapter
n PCs
(one RS232 each)
1 PC
(with n serial interfaces)
or
