Configuration
Basic configuration options
DMP41 A03470_07_E00_00 HBM: public 63
7 Configuration
This chapter looks at the functions and configuration options of the DMP41.
The menu structures shown below will help you find the required setting
menus more rapidly. We also show you at the same time the actual key
sequences to follow to make the settings.
7.1 Basic configuration options
Essential settings
The following essential settings can be made in setting mode:
A Bridge excitation voltage and measuring range
B Unit
C Linearization table corresponding to the transducer data
Simple measurements are now possible in measuring mode. You can
continue setting additional functions, as required.
A
B
C
