12.2 Determining the Charging Voltage
Determination of charging voltage at the stud welding unit using the arrow keys
depends i.a. on
– the stud welding gun used,
– the material of the welding element,
– the diameter of the welding element,
– the material of the workpiece.
Determine the charging voltage to be set at the stud welding unit using the fol-
lowing tables.
The gures in these table are indicative values and must be checked
by means of a test welding on the original material with the same pro-
perties as the original workpiece.
