!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!IPCAM User Manual
- 33 -
4.3 Specification
ITEMS IPCAM
Image Sensor 1/4" Color CMOS Sensor
Disaplay Resolution 640 x 480 Pixels(300k Pixels)
Lens f: 6mm, F:2.4 (IR Lens)
Image Sensor
Mini. Illumination 0.5Lux
Lens Type Glass Lens
Lens
Viewing Angle 67Degree
Image Compression MJPEG
Image Frame Rate 15fps(VGA),30fps(QVGA)
Resolution 640 x 480(VGA), 320 x 240(QVGA)
Flip Mirror Images Vertical / Horizontal
Light Frequency 50Hz, 60Hz or Outdoor
Video
Video Parameters Brightness, Contrast
Ethernet One 10/100Mbps RJ-45
Supported Protocol HTTP,FTP,TCP/IP,UDP,SMTP,DHCP,PPPoE,DDNS,
UPnP,GPRS
Wireless Standard IEEE 802.11b/g
Data Rate 802.11b: 11Mbps(Max.)
802.11g: 54Mbps(Max.)
Communication
Wireless Security 64/128-bit WEP Encryption
Pan/Tilt Angle Horizontal:120° & Vertical: 90°
Infrared Light
4 IR LEDs,Night visibility up to 5 metres
Alarm Input 1 Channel on/off input
Alarm Output 1 Channel relay output
Dimension
110(L) x110(W) x110mm(H)
Gross Weight
705g (Color Box Size:204x189x124mm)
Physical
Net Weight
400g ( accessories included)
Power Supply DC 5V/2.0A
Power
Power Consumption 5 Watts (Max.)
Operate Temper. 0° ~ 55°C (14°F ~ 122°F)
Operating Humidity 20% ~ 85% non-condensing
Storage Temper. -10°C ~ 60° (14°F ~ 140°F)
Environment
Storage Humidity 0% ~ 90% non-condensing
CPU 2.0GHZ or above (suggested 3.0GHz)
Memory Size 256MB or above (suggested 1.0GHz)
Display Card 64M or above
Supported OS Microsoft Windows 2000/XP/Vista
PC Requirements
Browser IE 5.0,IE 6.0, IE7.0, IE8.0, firefox2.0, firefox3.0 or other
standard browsers
Certification
CE,FCC
Warranty
Limited 1-year warranty
