Frequency Range PMR446 (446.00625MHz-446.09375MHz)
Channel Capacity 8 Channels
Operation Voltage 3.7V
Standard Battery 1500mAh
Battery Life (5-5-90 operation cycle) 8-12 hours
Frequency Stability 2.5 ppm (-20°C - +60°C)
Operation Temperature -30°C - +60°C
Antenna Impedence 50 Ω
Size 47mm x 81mm x 23mm
Weight Approximately 130g (without battery)
RF Power Output 0.5W
Modulation F3E
FM Sound 45dB(W)/42dB(N)
Transmission Current ≤ 1.4A
Sensitivity (12dB SINAD) 0.2uV
Image Rejection ≥ 60dB
Sound Output Power 500Mw
Receiver Current ≤ 400mA
Stand-by Current ≤ 75mA
24
English
TECHNICAL SPECIFICATIONS
HEIDER PRO5 PMR 446
