2-4
INFORMATION FOR PREPARATION
LOCKING TORQUE
Adopt the standard torque locking for the item unlisted.
STANDARD TORQUE：
Type Locking Torque (kg-m)
5 mm Screw 0.4
6 mm Screw 1.0
6 mm Hex Washer Face Bolt / Nut 1.2
8 mm Hex Washer Face Bolt / Nut 2.7
10 mm Hex Washer Face Bolt / Nut 4.0
CHASSIS：
Locking Place Quantity Dia. (mm) Locking Torque (kg-m)
Front Wheel Axle Nut 1 12 3.5
Rear Axle Nut 1 14 5.0
Rear Brake Arm Screw 1 6 1.2
Front Shock Absorber 4 10 4.0
Rear Shock Absorber 2 10 4.0
Engine Mounting Nut – Front 1 10 4.5
Engine Mounting Nut – Rear 1 8 3.0
ENGINE：
Locking Place Quantity Dia. (mm) Locking Torque (kg-m)
Screw of Cylinder Cap 4 6 1.0
Flywheel Nut 1 10 3.8
Clutch Cover Nut 1 10 3.8
Clutch Carrier Nut 1 28 5.5
Nut of Primary Fix Sheave 1 10 3.8
Oil-check Screw 1 8 1.3
Joint Screw of Exhaust Muffler 2 6 1.2
Exhaust Pipe Support Screw of Muffler 1 8 3.0
Spark Plug 1 14 1.4
Bolt of Crank Shaft Case 6 6 1.0
To Next Page
