HER CHEE ATV-90 - Tire and Buffer Device Checks; Power Transmission, Electric, and Engine Checks

3-2
Service Time (month)
Service Items
Before
riding
1st Each
6
each 12
Judgement Standard Remarks
Riding Device
Tire
Check & damage of tires
○ ○ ○
Ditch--- front wheel till 3 mm
Rear wheel till 3 mm
Abnormal & ditch in tires
○ ○ ○
Bolt & nut of tires locking
○ ○
Blocking torque
Front wheel – 3.0~3.5 kg-m
Rear wheel – 4.5~5.5 kg-m
Tightness of front bearing
○
Tightness of rear bearing
○
Buffer device
Spring - damage
○ ○
Spring of shock absorber.
Suspension arm – damage of joint gap
& arm
○ ○
- oil leakage or damage
○ ○
Tightness of installation
○ ○
Power transmission device
Clutch - action
○ ○ ○
Gear Box
○ ○
SAE 90 or 85W-140
Electric device
Ignition device - Spark plug
○ ○
Gap of spark plug 0.6~0.7 mm
Battery - connection of terminal
○
Wiring of electrical appliance – damage
or loose in connection place
○
Engine
Body – starting & abnormal noise
Low speed & accelerating
exhaust
air filter
○
○
○
○
○
○
○
○
○
Idle : 1800±100 rpm
