REMOVE OF ENGINE
Operation / Parts Name Q’ty Remarks
1
2
3
4
5
6
7
8
9
10
11
12
Disassembly
Oil Tank
Air Cleaner Ass’y
Tail of Muffler
ACG wire /wire of start motor
Starter wire of carburetor
Vacuum pressure tube
Cap of spark plug
Oil pump control cable
Throttle cable
Drive Sprocket Ass’y
Hex washer face bolt of engine
Engine
1
1
1
2
1
1
1
1
1
1
4
1
4WARNING:
The oil over-flow when remove the oil tube ,
so use clip or plug stop the seal.
4WARNING:
z Actually for brace the frame, avoid body
turn inside out.
Assembly
12→1
4WARNING: Carry out following adjusting
after installation.
–Cable of throttle valve
–Oil pump control cable
–Rear break cable
To Next Page
