Protocol description ASCII, SECS/HSMS
Customer manual
Version 1.2
LFM LP Reader 15.01.2019
Page 76 of 119
HERMOS AG
Gartenstrasse 19 Tel. +49(9279) 991-0
D-95490 Mistelgau Fax. +49(9279) 991-100
ATTRID Format: A[max25]
Name for an attribute for a specific object type.
CIDRW Attribut definitions:
"Configuration“ Number of heads
"AlarmStatus“ Current CIDRW sub-state of the alarm state
"OperationalStatus“ Current CIDRW sub-state in normal operation
“SoftwareRevisionLevel" Change (version) of the software - maximum 8 bytes
"CarrierIDOffset" Offset of the CID in the CID field (MID area)
"CarrierIDLength" Length of the CID in the CID field (MID area)
"SERIALNUM" Series number string
"HARDWARE" String of the Hardware-Release
"SELF_TEST_RESULT" Supply the result of the last self-test
"MANUFACTURER" String of the manufacturer
"ECID_00" Parameter 0 Gateway ID
"ECID_01" Parameter 1 Baudrate
"ECID_02" Parameter 2 Inter-character timeout T1
"ECID_03" Parameter 3 Block protocol timeout T2
"ECID_04" Parameter 4 Reply timeout T3
"ECID_05" Parameter 5 Inter-block timeout T4
"ECID_06" Parameter 6 Retry limit RTY
"ECID_07" Parameter 7 TARGETID high byte
"ECID_08" Parameter 8 TARGETID low byte
"ECID_09" Parameter 9 Heartbeat time
"ECID_11" Parameter 11 ReaderID
"ECID_12" Parameter 12 HeadID
"ECID_20" Parameter 20 Sensor Delay for presence sensor
"ECID_22" Parameter 22 Sensor triggered action for presence sensor
"ECID_23" Parameter 23 Triggered read frequency
"ECID_24" Parameter 24 r/w max repeat
"ECID_25" Parameter 25 Transponder Type
"ECID_26" Parameter 26 Sensor activity
"ECID_27" Parameter 27 Sensor Watchport for presence sensor
"ECID_28" Parameter 28 Negate external output
"ECID_29" Parameter 29 Transponder load duration (read mode)
"ECID_30" Parameter 30 r/w synchronize
"ECID_33" Parameter 33 Automatic Antenna adjustment
"ECID_34" Parameter 34 Sensor type for presence sensor
"ECID_35" Parameter 35 Special features
"ECID_36" Parameter 36 Push button switches activation
"ECID_37" Parameter 37 MID area
