Protocol description ASCII, SECS/HSMS
Customer manual
Version 1.2
LFM LP Reader 15.01.2019
Page 80 of 119
HERMOS AG
Gartenstrasse 19 Tel. +49(9279) 991-0
D-95490 Mistelgau Fax. +49(9279) 991-100
Value of the reader parameter.
The values are displayed as decimal values, see Parameter
Where used S2F14, S2F15
MDLN Format: A[6]
Plant model number (Hardware Version)
Where used S1F2
MF Format: B[1]
Material Format Code
20: The material port number corresponds to the sensor number and the sensor status.
Where used S3F5, S3F7
MHEAD Format: B[10]
The data element MHED consists of the head of the SECS message block associated with the
defective message block.
Where used S9F1, S9F3, S9F5, S9F9
MID Format: A
Material ID, predefined area on the transponder in which the unique identifier of the cassette / box is
stored. Depending on the type of transponder, the length of the MID can be changed.
Multipage-Transponder: The MID length can be set from "0" (no MID) to "10" (MID occupies the
first 10 pages).
Read-Write-Transponder: The MID corresponds to the DATA (writable)
Read-Only-Transponder: The MID corresponds to the DATA (fixed)
Where used S18F10, S18F11
Please note the parameters 42-45
MIDAC Format: B[1]
Material ID verification code
0 Material ID confirmed; the presence sensor was the initiator
1 Not specified
2 Material ID confirmed - reaction to externally triggered process; the message can not be
assigned to a sensor
>2 Material ID not confirmed
The initiator can be taken from the data element PTN.
Where used S3F14
MIDRA Format: B[1]
