Protocol description ASCII, SECS/HSMS
Customer manual
Version 1.2
LFM LP Reader 15.01.2019
Page 79 of 119
HERMOS AG
Gartenstrasse 19 Tel. +49(9279) 991-0
D-95490 Mistelgau Fax. +49(9279) 991-100
The number of LEDs per antenna input depends on the design of the
hardware.
DATA Format: A[max200]
The data element is a vector or string of unformatted data.
The DATA area depends on the MID area of the transponder and can be between page 1 and page 17.
Read-write transponder DATA corresponds to 8 byte MID
Read-only transponder DATA corresponds to 8 byte MID
Where used S18F6, S18F7
DATALENGTH Format: U2
The DATA LENGTH corresponds to the number of bytes to be read or written. The scope depends on
the length of the MID range (parameter 37).
Where used S18F5, S18F7
DATASEG Format: A[2]
Used to identify the requested data.
The DATASEG corresponds to the page number (PAGEID) of the transponder.
"00" First page of each transponder or first page of the DATA area.
Multipage transponders (pages 1 to 17):
"01" page 1 "81" Locked page 1
... ... ... ...
"11" page 17 "91" Locked page 17
Read-Only-Transponder "F0" Read only one page
Read-Write-Transponder "F1" Read or write only one page
Where used S18F5, S18F7
EAC Format: B[1]
Confirmation code for new reader attribute
0 ... parameter successfully set
1 ... parameter could not be set
Where used S2F16
ECID Format: U1
Parameter number of the reader.
The values are displayed as decimal values.
Where used S2F13, S2F15
ECV Format: U1
