ECID_00 bis ECID_99 see data element ECV parameters 0 - 99
Head attribute definitions:
"HeadStatus" Current state
"IDLE" ... Reader in REST mode
"BUSY" ... reader is busy
"NOOP" ... Not in operation
"HeadID" corresponds to the 2-digit target ID of the first antenna port
„01“
Where used S18F2, S18F3
ATTRVAL Format: A[max2]
State request value
OpStatus Operating status, maintenance or rest mode
"OP" ... operating status
"MT" ... maintenance status
LEDStatus LED-status
"Off" ... switch off the LED
"On" ... switch on the LED
"Flash" ... switch the LED to flashing mode with 1Hz
LedNo LedNo LED-number, 1Byte
"1" externe LED of the port
"2" red LED TEST
"3" blue LED TEST
"4" green LED TEST
"5" red LED TUNING
"6" blue LED TUNING
"7" green LED TUNING
"8" red LED STATUS
"9" blue LED STATUS
"A" green LED STATUS
Timeout Timeout duration, Units seconds
„00“: permanently
„01“ to „FF“: Timeout from 1 to 255 s. After the timeout, the LED goes off.
Where used S18F13
