iRTK5 Smart GNSS System User Manual
38
Internal radio
Built in Transceiver Radio
Transmitting power: 1W/2W/4W adjustable
Frequency: 403MHz-473MHz
Protocol: HI-TARGET, TRIMTALK450S, TRIMMARKⅢ,
TRANSEOT, SOUTH, CHC, SATEL.
Channel: 116 channels, 100~115 channels are configurable)
External radio
HDL radio
Transmitting power: 10W/30W adjustable,
Frequency: 403~473MHz
Protocol: HI-TARGET, TRIMTALK450S, TRIMMARKⅢ,
TRANSEOT
Communication: built-in 4G network communication, WIFI,
Bluetooth, NFC
Channel: 48 channels (16 of which are configurable)
Working mode: external radio, network relay, radio relay
Sensor
Electronic bubble
Intelligent levelling
Calibration-free tilt
survey
[2]
Tilt correction system will continue to monitor the inclination of
the centering rod, and compensate to correct the coordinates
Built-in high-precision inertial navigation, automatic attitude
compensation, no need for correction, anti-magnetic
interference, and accuracy is 2~3 cm (within 30 degrees).
Temperature sensor
Intelligent temperature control
User Interface
Button
Single button
Touch screen
Industrial OLED color screen (240 * 240); capacitive touch,
waterproof, supports glove operation
LED Lamp
Satellite lamp, signal lamp, power light
Application
Function
Advanced function
OTG, NFC, WebUI, USB firmware upgrade, network delay, radio
delay.
Intelligence application
Intelligent voice, self-test function, intelligent battery, battery
quick charge.
Remote service
Message delivery, remote upgrade, remote control.
Physical
Internal battery
6800mAh lithium-ion battery with charge display, RTK rover
(network) ≥10 hours
[3]
External power
6-28V DC external power input (5-pin port) with over-discharge
protection
Dimensions
Φ158mm×98mm
