Receiver Introduction
10
transmitting power,satellite elevation angle,automatically
base setting, reset receiver and so on.
Function Key: settings of data link, UHF radio channels,
collection interval, back to original setting.
Power Key: setting confirmation, automatically base
setting and so on.
Upper Cover
Figure 3-3 indicates the upper cover of V30 receiver, the
main function of which is anti-drop and anti-scratch.
Figure 3-3 Upper Cover
Raised Point: anti-wear point to avoid instrument being
scratched
Raised Plate: 5 raised plates can avoid wear-out and falling
Raised Plate
Raised Point
