Hi-Target V30 User Manual

V30 GNSS RTK System Manual
67
Point: All above are for facing the main frame,
it’s the face icon for the socket of bottom
main frame ( The plug welding surface)
Differential Antenna
Figure 8-3 Differential Antenna
Refer to Figure 8-3, the differential antenna is an essential
part both to Base and Rover with internal UHF radio, which
transmits the UHF differential signal for Base while receiving
the UHF differential signal for Rover.
 Differential Antenna Installation
Refer to Figure 8-4，holding the bottom of differential
antenna and assemble it with clockwise rotation. On the
contrary you can disassemble the differential antenna.

Hi-Target V30 Specifications

General

Brand	Hi-Target
Model	V30
Category	Receiver
Language	English
