Configuration of Fieldwork
48
Diagram for rover working
Figure 5-4 UHF rover Figure5-5 GPRS/3G rover
Carbon
fiber
centering
pole
Bluetooth
Controller
UHF
receiving
antenna
Rover receiver
mainframe
Bluetooth
Rover receiver
mainframe
Carbon
fiber
centering
pole
Controller
