V30 GNSS RTK System Manual
51
Double click F1 with the voice prompt “base”, “rover”
and “ static” to choose the working mode you need, press
power button to confirm the setting.
2. Set UHF data link
Double click F2, then choose UHF mode from UHF,GSM
and external radio then click the power button to confirm.
3. Set UHF radio channel
Hold F2 button with voice prompt to choose the channel
in need, press power button to confirm.
Note: Base and rover must be in the same
channel for a normal work.
The differential signal is being transmitted while the
signal light (red) is flashing once at one second. Meanwhile,
the rover have received the signal while the signal light (red)
of rover is flashing synchronously once at one second. Now
RTK work can be started. If the signal led (red) of rover does
not flash, that means it has not received the differential signal.
4. Set the power of radio:
When the working distance becomes farther, you can set
the power of the radio of the base through the control panel.
Pressing F1 button until hearing the voice prompt: high,
medium, low, the working distance is getting lower in
